In recent years, my country’s call for energy saving and emission reduction has become higher and higher, and the demand for energy-saving equipment is also increasing. Increasing the intensity of energy conservation has also become a realistic task faced by the air compressor industry. The frequency conversion air compressor is an energy-saving air compressor, and its advantages are as follows:
Set the pressure freely and maintain a constant supply pressure
1. Under the set required pressure, the unit will always maintain a constant pressure supply of +0.1bar pressure:
2. Satisfy the user to set the pressure arbitrarily within the range of 3~14bar, without changing gears or belts.
(Note: The maximum pressure value should be determined when purchasing the machine);
3. When the gas consumption is small, the pressure remains unchanged and the speed automatically decreases, satisfying only enough gas.
4. When the gas consumption is large, the pressure remains unchanged and the speed is automatically compensated to ensure the gas supply needs.
Can be controlled remotely
Using advanced control, monitoring and communication systems, through the Internet, users can conveniently obtain timely technical assistance from suppliers all over the world.
Energy saving
Compared with the traditional air compressor, the air compressor installed with the frequency converter can automatically adjust the operation of the air compressor according to the air consumption, which can save energy, and the effect is remarkable.
Efficient power saving
1. With the variable speed control technology, the displacement of the compressor can be perfectly combined with the gas consumption of the user, completely avoiding the loss of unloading power:
2. In the state of intermittent gas consumption, the zero-load effect of soft start avoids the peak value of current and torque, so the unit can start and stop infinitely. Really achieve 0~100% stepless speed change, and control the generation of useless work to the greatest extent;
3. Eliminate the extra pressure burden of 2bar, so that the air compressor unit can directly save energy by 14%, because every reduction of 1bar working pressure can save 7% of energy loss.
Extend the service life of the air compressor
The frequency converter starts the air compressor from 0Hz, which can adjust the start time of the air compressor, thereby reducing the impact on some electrical or mechanical components inside the air compressor during startup, enhancing system reliability and extending the service life of the compressor. extend.
In addition, variable frequency control can reduce current fluctuations when the unit starts, which can affect the power consumption of the grid and other equipment. The frequency converter can effectively reduce the starting current peak to a minimum.
More reliable
1. Frequency conversion soft start avoids electrical shock and avoids mechanical shock.
2. Eliminate the unfavorable factors of long-term high-speed operation of the unit.
3. No contactor to avoid electrical contact failure.
4. Exempt from 2bar high pressure, reducing the probability of system leakage.
Energy saving and environmental protection, equipment in place, immediately put into use
Frequency conversion air compressor units do not need special installation foundation, low-speed axial fan and modern vibration isolation and noise reduction measures make the compressor running with very low noise, so it is convenient for users to place it on the production site. As long as the equipment is in place, the pipeline can be quickly Connect and start running immediately.
Reduced the noise of the air compressor
After installing the frequency converter, the speed of the motor will be significantly slowed down under the required working conditions of the compressor, and the noise generated by the air compressor will be significantly reduced. According to the on-site inspection, the current noise is 3-7 decibels lower than the original noise.
